FEATURES
- low insertion loss & high isolation
- Excellent thermal stability
- Optical pa h epoxy free
- Telcordia compliant
- RoHS compliant
APPLICATIONS
- WDM system
| Parameter | Specification | Unit | ||||
| Operating Wave- length | 1310/1550 | 1550/1310 | 1550/1480 | 1550/980 | ||
| Transmission Wavelength Range | 1270~1350 | 1500~1600 | 1530~1570 | 1530~1570 | nm | |
| Reflection Wave- length Range | 1500~1600 | 1270~1350 | 1460~1500 | 960~1000 | nm | |
| Transmission I nsertion Loss | Max | 0.8 | 0.8 | 0.8 | 0.8 | dB |
| Reflection Inser- tion Loss | Max | 0.6 | 0.6 | 0.6 | 0.6 | dB |
| Passband Ripple | Max | 0.3 | 0.3 | 0.3 | 0.3 | dB |
| Transmission Isolation | Min | 30 | 30 | 30 | 30 | dB |
| Reflection Isola- tion | Min | 15 | 15 | 15 | 18 | dB |
| Return Loss | Min | 45 | 45 | 45 | 45 | dB |
| Directivity | Min | 45 | 45 | 45 | 45 | dB |
| Polarization De- pendent Loss | Max | 0.1 | 0.1 | 0.1 | 0.1 | dB |
| Operating Temper- ature Range | 0~+70 | °C | ||||
| Storage Tempera- ture Range | -40~+85 | °C | ||||
| Maximum Power Handling | 300 | mW | ||||
| Package Dimen- sion (L * Ø) | 38*5.5 | mm | ||||
| F-WDM | Channels | JUMPER TYPE | CONNECTOR | FIBER LENGTH |
| 1: T 1260-1360 | B: 250um | 0: None | 10: 1.0m 15: 1.5m | |
| 2: T1480-1500 | 9: 900um | 1: SC/UPC | 18: Other 3: FC/UPC | |
| 3: T1540-1560 | 8: Other | 2: SC/AP | 4: FC/APC 5: LC/UPC | |
| 4:1550/980 | 6: LC/SPC 7: MU/UPC | |||
| Customed | 16: Other |
